RGP10-P

Semiautomatic forming line for pipe production

The line consists of:
• Sheet metal decoiler
• Roll forming machine
• Cutting system
• Drop table
• Operation control panel





Technical characteristics:
• It makes gutter pipe shapes of an unlimited length, from different materials: steel sheets, zinc or plastic plated, 0.45- 0.55 mm in thickness, steel grades C0147 and C0148, hardness HT28 and HT30; copper sheets 0.7 mm thickness, suitable for further shaping by plastic deformation; Al plain or colored sheets 0.5- 0.7 mm thickness.
• Loaded sheet metal width: B=333 mm
• Drive: electric motor 4,0kW, 380 W
• Izlazni broj obrtaja reduktora 78 o/min
• Machine capacity: 250 m/h
• Compressed air pressure necessary- 4-9 bar
• Machine weight: cca 1100 kg
• Overall machine dimensions: 800x900x7500



1. Mašina za izradu olučne cevi TIP RGP10-P, B=333mm

Linija se sastoji od:

· Odmotača lima

· Mašine za profilisanje

· Sistema za odsecanje gotovog profila

· Prihvatnog stola

· Komandno – upravljačkog pulta

Tehničke karakteristike:

  • Izrađuje profil olučne cevi neograničene dužine, od različitih materijala: čelični pocinkovani i plastificirani lim debljine od 0,45 – 0,55 mm, kvaliteta Č.0147 i Č.0148, tvrdoće HT28 i HT30, specijalno umiren; bakarni lim debljine 0,7 mm sa svojstvima za obradu plasta deformacijom; Al neobojeni i bojeni lim debljine 0,5 – 0,7mm.
  • Širina ulazne trake: B=333mm
  • Pogon: el. motor 4,0 kW, 380W
  • Izlazni broj obrtaja reduktora 78 o/min
  • Kapacitet mašine: 250m/h
  • Potrean pritisak komprimovanog vazduha 4 - 9 bar
  • Težina mašine: cca 1100 kg
  • Gabaritne mere mašine: 800x900x7500
